Precision Testing for Thermal Efficiency & Durability
Servo Enterprises’ Piston Cooling Jet is a high-precision laboratory equipment made to evaluate and validate the cooling performance of piston oil jets in internal combustion engines. Built for R&D centers, automotive manufacturers, and engine testing laboratories, this test rig replicates engine operating conditions to measure spray patterns, flow rate, temperature control, and pressure dynamics of piston cooling jets.
Crafted with advanced instrumentation and real-time data logging, the rig provides engineers with actionable insights into thermal regulation, component durability, and overall engine efficiency. Its modular design and programmable test parameters make it an indispensable tool for modern engine development.
Realistic Engine Condition Simulation
Accurately mimics oil pressure, flow rate, and temperature to replicate actual engine environments.
Clear Spray Observation Chamber
Transparent enclosure allows direct visualization and evaluation of oil jet spray patterns.
Precision Flow & Pressure Monitoring
Equipped with high-accuracy digital sensors for precise control and measurement.
Advanced Temperature Regulation
PID-controlled heating system ensures stable and adjustable oil temperature during testing.
Real-Time Data Acquisition
Integrated logging system captures live test data for monitoring and post-test analysis.
Versatile Jet Testing Platform
Modular setup allows for seamless adaptation to different jet designs and testing requirements.
| Product Name | Servo Piston Cooling Jet Test Rig |
| Application | Automotive Engine Piston Cooling Jet Testing |
| Pump Type | High Pressure Gear Pump |
| Pressure Range | 0 – 10 bar |
| Flow Range | 0.5 – 10 LPM |
| Oil Temperature Control | Ambient to 100°C |
| Test Modes | Continuous, Pulsed, Thermal Cycle |
| Supported Jet Types | Single / Dual / Custom Nozzle |
| Oil Tank Capacity | 40 – 80 Litres (SS 304) |
| Drive System | VFD Controlled Motor |
| Sensors | Flow, Pressure, Temp, Spray Monitoring |
| Control System | PLC + HMI / PC-Based |
| Data Logging | USB / Ethernet (Real-Time) |
| Spray Visualization | Transparent Chamber + Camera (Optional) |
| Safety Features | Emergency Stop, Oil Cutoff, Overload |
| Compliance | ISO / OEM Testing Standards |
| Power Supply | 230V / 415V, 50Hz AC |
| Brand | Servo Enterprises |
| Country of Origin | Made in India |
At Servo Enterprises, we bring engineering excellence and customization capability to every test rig we build. Our Piston Cooling Jet Test Rig is a result of in-depth industry collaboration, built to support more advanced innovation in the automotive and powertrain sectors.
